32mm Planetary Gear Motor Reducer 12V DC 24V DC Customized

1. Item name: Gear Motor Reducer 32mm planetary gear motor with high quality and high efficiency

1) Small size dc gear motor with low speed and big torque

2) this gear motor provide 7NM~ torque and more realiable.

3) Suitable to low noise and big torque application

4) Available reduction ratio:

First stage: 3.11. 3.71, 4.8, 5.75/  9.68, 11.56, 13.8, 14.93, 17.83, 17.89, 21.36, 23.04, 27.6, 33.06/

2nd stage: 30.11, 35.95, 42.92, 46.46, 51.24, 55.47, 55.65, 66.22, 66.44, 71.68, 79.68, 79.33,

85.58, 85.87, 102.51, 10.86, 110.59, 122.8, 132.48, 158.7, 190.11

3rd stage:  93.68, 111.85, 133.53

2. HYX-P32H Planet gear box  dimensions

Allowable motor speed max. : 6000 rpm

Allowable max. radial load: <=50N

Allowable max. axial load: <=50N

Allowable max. installing force: <=100N

Radial clearance: <=0.03mm

Axial clearance: <=0.03mm

Recommended temperature range: -40°C to +125°C (-10°C to +85°C for plastic gears)

Voltage, rated torque, speed, Current, Power and shaft dimensions can be customized as per customers' requirement.

3. Technical parameters

4. Application Scenario

1) Household appliances: Electric curtains, integrated stoves, coffee machines, smart toilets, robot vacuums, dishwashers, range hoods, smart door locks
2) Personal care: hair curlers, massage instruments, electric hair clippers
3) Office equipments: shredders, printers, projectors, banknote counting machines, coin counting machines
4) Medical equipment: massage chairs, electric carts, medical pumps, electric beds, electric wheelchairs
5) Industrial equipment: water and electrical valves, air switches, pumps, automatic door switches, automatic lubrication equipment
6) Commercial equipment: vending machines, parking locks, ATM machines, smart lamps
7) Robots: manipulators, drones, service robots

5. FAQ

Q1: Are you a trading company or a manufacturer?
A:We are a factory which has been specialized in cnc machining, PM/MIM, Plastic injection molding, precision casting etc.

Q2:What's your terms of payment?

A: 50%T/T as the upfront deposit, 50% before delivery,We will show you the photos and package before you pay the balance.

Q3: What about the lead time?
A:Sample need 20-25 days, mass production 25~30 days generally.

Q4. How to get an accurate quotation?
1) Drawings including tolereance requirement or photos or samples of products.

2) Detailed sizes of products.
3) Material of products
4) Surface treatment of products.
5) Ordinary purchasing quantity.

Please kindly tell us your specific requirement and then we will offer you accordingly soon.
